XSZ-N107SM-CM Digital Microscope with Camera Viewing Head OEM/ODM

Home / Products / Microscope / Digital Microscope / XSZ-N107SM-CM Digital Microscope with Camera Viewing Head
XSZ-N107SM-CM Digital Microscope with Camera Viewing Head

XSZ-N107SM-CM Digital Microscope with Camera Viewing Head

The digital microscope with a camera viewing head refers to a type of microscope that has a built-in camera in the viewing head. This allows users to capture images and videos of the magnified specimens directly from the microscope. The camera viewing head often has controls for adjusting image parameters such as brightness, contrast, and resolution. It may also have built-in software or connectivity options to transfer the captured images and videos to a computer or other devices. Having a camera viewing head eliminates the need for an external camera or additional equipment to capture and document the observations made under the microscope.
Contact Us
PREV：XSZ-107SM-CM Multi-Purpose Digital Microscope with Trinocular HeadNEXT：XSZ-N107SM 140X140mm digital microscope with 7inch screen
  • Product Details
  • About Fangyuan
  • Contact Us
Specification
Achromatic Objectives 4X、10X、40X（S）、100X（S、Oil）
Eyepiece Wide Field Eyepiece ：WF10X、（WF16X optional）
Viewing head Compensation Free Trinocular Head  , camera
Stage Double Layer Mechanical Stage Size 140X140mm,Moving Range 75X45mm
Focusing Coaxial Coarse and Fine Adjustment,Focusing Range 30mm,Focusing Interval 0.002mm
Condenser Abbe NA=1.25 with lris Diaphragm&Filter
IIIumination Halogen Lamp 220V/6V20W or 110V/6v20W ； (LED lam optional)
